Specialty / Industrial Printers

MUTOH ValueJet 1638UH Mark II

A 1625mm/64” wide Hybrid UV LED Printer with dual head/dual lamp for real production. The ValueJet 1638UH MarkII is a next-generation UV LED printer with the newly developed MUTOH’s intelligent interweave print technology.

MUTOH ValueJet 1638UH Mark II Specialty / Industrial Printer

Features

The ValueJet 1638UH MarkII is a next-generation UV LED printer with the newly developed MUTOH’s intelligent interweave print technology “i-WeaveUVEx” run by MUTOH genuine RIP software “VerteLith”, which allows you to maximize your print quality while still maintaining faster production speeds.
The “i-WeaveUVEx” expands print mode options for optimal print on desired applications. The VJ-1638UH MarkII is ideally suited for the production of high quality graphics : in-store promotional prints & deco graphics, POP & retail graphics, floor & window prints, customized wall décor prints, stickers, sign blanks, exhibition graphics, fine art prints, packaging samples and more.

Features:

1625mm/64″ UV LED hybrid printer
Dual print heads for increased production
UV LED ink : flexible or rigid types – 6 colors (CMYK + Wh + Va)
White ink circulation system integrated
Variable Dot Technology
Automatic media thickness measurement & head
height adjustment up to 15mm
Roller pressure controlled manually with a simple lever
Rigid front and rear tables(option)
Optional take-up systems
Optional media retainer

Applications:

Specifications

Model Name		VJ-1638UH MarkⅡ
Printer Technology		Drop-on-demand Micro Piezo Inkjet Technology
Print Head		2 (staggered setup)
Print Head Height		Low: 1.5mm High: 2.5mm (2 step system by manual)
Maximum Media Width		1625mm
Maximum Printable Width		1615mm
Maximum Media Thickness		15mm
Media Measurements		Roll media: φ150mm/ 2″ & 3″ / 30kg or less
Media Measurements		Rigid media: Max. length 1200mm / Min. length 200mm / 15kg or less
Ink	Type	UV LED ink (flexible type: US11 ink /Rigid type: UH21 ink)
	Ink set	4 colors（C, M, Y, K）/ 5 colors (CMYK+Cl+Va) 6 colors （C, M, Y, K, White + Varnish）
	Volume	220ml (C, M, Y, K, White+Varnish) 800ml (C, M, Y, K, Varnish) 500ml (White)
	No. of slot	8
Maximum Print Resolution		1440x1440dpi（16 pass）
Interface		Ethernet (10/100BASE-TX, 1000BASE-T)
Power Requirements		AC100-240V, 50/60Hz
Printable Environment		Temperature: 20-32℃ < Recommended environment: 22-30℃ >
Printable Environment		Humidity: 40-60%RH (non condensing)
Power Consumption		<Main> Operation status: 770W or less / Standby: 52W or less
Dimensions (WxDxH) / Weight		Body including stand: 2983x818x1261mm / Body: 160kg Stand: 37kg
Dimensions (WxDxH) / Weight		Printer including media feeding table: 2983x2730x1261mm Optional media feeing table: 43kg
Take-up System (optional)		30 kg and 40kg take-up systems/100kg feed and take-up system

*The specifications are subject to change without notice.
*500/800ml bags require optional adapter.
