Eco-Solvent Printer
MUTOH ValueJet 1324X
A 1371mm/54″ Wide High Quality Printer for durable graphics, offering small size and big possibilities. With the amazing ValueJet 1324X from MUTOH, you get a high-performance 1371mm/54” eco-solvent printer featuring cutting-edge print technology and precision engineering for a surprisingly affordable price.
Features
Ideal for small to mid-range sign makers & print providers, the VJ-1324X single head sign & display printer delivers unrivalled print quality and an unprecedented level of ease of use! Flexible, reliable and able to deliver excellent print quality for short print runs as well as volume production runs, the robustly built & cost-effective VJ-1324X delivers sellable production speeds up to 27.9m²/h at 720x720dpi and will prove to be a reliable workhorse for all high-quality indoor and outdoor graphics. A perfect match for businesses with medium and higher print volumes.
Features:
- Choice of the MUTOH original eco-solvent inks:
- MS31 ink or Ultra Value ink (1L-ink bag)
- Up to 4 color capability
- Variable Dot Technology
- 2 steps head height (1.2mm or 2.0mm)
- Media heating system
- Equipped the automatic cutting function
- Take-up system included (up to 20kg)
- Easy daily maintenance
Applications:
Specifications
| Model Name | VJ-1324X | |
|---|---|---|
| Print Technology | Drop-on-demand Micro Piezo Inkjet Technology | |
| Print Head | 1 | |
| Head Heights | Low:1.2mm / High: 2.0mm | |
| Max. Media Width | 1371mm | |
| Max. Print Width | 1361mm | |
| Ink Type | Eco-solvent ink | |
| MS31 ink | Ink Colors | KCMY-4 colors |
| Ink Volume | 220ml / 1000ml bag (Need dedicated adapters) | |
| Ultra Value ink | Ink colors | KCMY-4 colors |
| Ink Volume | 1000ml bag (Need dedicated adapters) | |
| Print Resolutions | 1440/720/360dpi (12 modes as standard + 19 modes as custom**) | |
| Interface | Ethernet (10BASE-T/100BASE-TX) | |
| Media Measurements* | φ150mm/ 2″ &3″ / 20kg or less | |
| Heater Control System | Pre-heater / Platen-heater / After-heater（30-50℃）, OFF | |
| Power Supply | AC 100-120 V / AC 200-240V – 60/50 Hz | |
| A-property Acoustic Power Level (Actual Measured Value) | 67.7dB or less | |
| Printer Accuracy Guaranteed Environment | Temperature: 20～30℃ Humidity: 40～60%RH (Non Condensing) | |
| Power Consumption | Operating Status: 1550W or less, In standby: 45W Take-up system: 32W or less | |
| Machine Measurements | W 1916 x D 659 x H 357mm | |
| Packing Size | Printer: W 2035 x D 435 x H 585mm, Weight: 96kg | |
| Stand: W 1510 x D 435 x H 260mm, Weight: 24kg | ||
| Take-up system: W 1971 x D 341 x H 409mm, Weight: 25kg | ||
| Printer Weight | 82.3kg including a stand | |
| Option | 1,000ml cartridge adapter VJ-HCIPADPT | |
| Cutter blade VJ-CB | ||
*Due to the removal of the flange joint, the 2-inch media core can be adjusted; however, do not use the solid 2-inch core media.
**Custom modes are set by the RIP software. For the details, please contact your authorized dealer.
**Custom modes are set by the RIP software. For the details, please contact your authorized dealer.
